When weight accuracy and throughput both matter, the BPS 14-Head Linear Combination Scale with tray filling system is built to deliver both. Designed for food manufacturers, produce packers, snack producers, frozen food processors, and industrial parts packagers, this weighing system combines 14 independent scale heads with a high-speed tray filling interface — achieving production throughput and weight accuracy levels that manual weighing simply cannot approach.
Linear combination scales operate on the principle of combinatorial weighing: each of the 14 scale heads holds and weighs a charge of product simultaneously. The control system evaluates all possible combinations of head weights in real time, selects the combination closest to the target weight, and discharges those heads into the package below. The cycle then repeats — replenishing discharged heads and solving the next optimal combination — typically at rates of 30 to 70 weighments per minute depending on product and target weight.
Over 45 years of packaging automation experience. One phone call: 888-814-7999.
BPS 14-Head Linear Scale System — Live Demonstration
Understanding the weighing architecture helps production engineers and plant managers evaluate the 14-head linear system against their specific product, target weight, and throughput requirements.
Product is conveyed into an overhead infeed system — typically a vibratory conveyor or Z-bucket elevator — and distributed across the 14 holding hoppers above the scale heads. Each holding hopper receives and holds a charge of product waiting to be released to the scale hopper below.
Product drops from each holding hopper into the corresponding scale hopper below it. The scale hopper contains a load cell that measures the exact weight of the charge. All 14 scale heads weigh simultaneously — giving the combination algorithm 14 independently known values to work with in real time.
The PLC evaluates all possible combinations of the 14 scale head values — up to 16,383 unique combinations for 14 heads — and selects the combination of heads whose combined weight is closest to the target weight within the programmed tolerance. This is the "combination weighing" advantage: consistently hitting target weight without overfill giveaway.
The selected heads open and discharge the combined weight into the chute below — dropping into the tray, bag, or pouch positioned beneath the scale. Discharged heads are simultaneously replenished from the holding hoppers above, and the cycle repeats at the programmed rate. The system can also signal the downstream bagger or tray sealer to trigger the packaging cycle in sync with the scale discharge.
| BPS 14-Head Linear Combination Scale — Technical Data | |
|---|---|
| Scale Heads | 14 independent load cell weighing heads |
| Weighing Accuracy | Within ±1 gram (product and hopper configuration dependent) |
| Output Speed | 30–70+ weighments/min (product dependent) |
| Target Weight Range | Configurable across a broad range — contact BPSG |
| Hopper Capacity | Various capacities — matched to product bulk density |
| Control Interface | 7-inch color touchscreen HMI (PLC-based) |
| Product Memory | Multiple product programs stored and recalled |
| Construction | Stainless steel hoppers and contact surfaces |
| Modular Control | Modular control system for serviceability |
| Power | Contact BPSG for electrical specifications |
| Downstream Interface | VFFS baggers, flow wrappers, tray sealers, trays |
| IP Rating | IP65 (washdown-compatible configuration available) |
Specifications subject to change. Contact BPSG at 888-814-7999 for application-specific configuration and pricing.
Ask About the BPS AX Linear Scale Series
BPSG also offers the BPS AX series linear scale — a complementary weighing platform for different product and throughput configurations. View the full linear scale systems overview or call us to compare options.
Linear Scale Systems OverviewThe 14-head linear combination scale is the weighing system of choice for medium-to-high-volume production operations packaging irregular, granular, or chunky products where consistent weight accuracy and production throughput are both primary KPIs.
Potato chips, tortilla chips, pretzels, popcorn, pork rinds, trail mix, nut blends, cheese puffs, and similar irregular snack products are ideal for the 14-head linear combination scale. The combination weighing algorithm consistently hits the labeled net weight with minimal overfill giveaway — directly reducing cost of goods per bag. Integrates with VFFS baggers for pillow bag, gusseted bag, or flat-bottom bag output.
Baby carrots, salad mix, broccoli florets, green beans, diced peppers, corn, peas, edamame, and similar fresh-cut or IQF frozen vegetable and fruit products run efficiently through the 14-head system. The stainless steel food-contact construction and washdown-compatible IP65 configuration support the sanitation requirements of fresh and frozen food production environments. Output goes directly into trays, bags, or pouches.
IQF shrimp, meatballs, chicken nuggets, fish portions, dumplings, pierogi, tater tots, and similar frozen food products are reliably weighed and discharged by the 14-head linear scale at production rates that support modern frozen food packaging lines. BPSG has commissioned linear scale systems in frozen food production environments and understands the specific requirements of cold-environment weighing operations.
Screws, bolts, nuts, washers, anchors, cable ties, hooks, and similar small hardware and fasteners are a growing application for the 14-head linear scale. Industrial parts packagers use the combination weighing system to hit count-weight targets with the accuracy needed for retail display packaging. Output goes into retail bags, trays, or blister-backed clamshells via downstream packaging equipment.
Whole bean and ground coffee, loose-leaf tea, chocolate-covered nuts and raisins, hard candies, gummy candies, and similar confection products run through the 14-head system with the weight accuracy needed for retail compliance. The combination algorithm minimizes the overfill cost that compounds significantly at high production volumes across multiple SKUs.
The 14-head linear scale pairs directly with tray filling and tray sealing systems for retail-ready produce trays, meat and seafood trays, and multi-serve meal component trays. The scale discharges a precisely weighed portion directly into the tray below at a rate synchronized to the tray sealer downstream. BPSG supplies both the scale and the downstream tray sealing equipment as an integrated system.
The BPS 14-Head Linear Combination Scale is designed to be the upstream weighing module in a complete automated packaging line — not a standalone weighing station. BPSG's 45-year systems integration capability means we supply, commission, and support the full line: from product infeed through scale, bagger or tray filler, checkweigher, metal detector, labeler, case erector, and case sealer.
The most common 14-head linear scale configuration places the scale directly above a vertical form-fill-seal bagger. The scale discharge chute delivers the weighed portion into the bagger's forming tube mouth — timing the discharge to coincide with the bag's open window. The bagger seals the bag and indexes to the next cycle. BPSG has commissioned 14-head + VFFS combinations producing pillow bags, gusseted side-seal bags, and flat-bottom bags across food and non-food applications.
For products that run in a flat or formed tray format, the 14-head linear scale feeds a HFFS horizontal flow wrapper through an intermediate tray loader or conveyor. The weighed portion is placed into the tray, the tray is conveyed into the flow wrapper, and the wrapper forms a film envelope around the loaded tray with a fin or lap seal. Retail-ready fresh produce trays are a common example of this configuration.
BPSG routinely adds an inline checkweigher immediately downstream of the bagger or tray filler to verify that each filled package meets the minimum net weight standard. Packages below the minimum weight tolerance are automatically diverted. The checkweigher provides a continuous weight verification record that supports trade measurement compliance and internal quality control reporting. BPSG supplies both the linear scale and the checkweigher.
BPSG's single-source capability means your 14-head linear scale project can include the complete packaging line: Z-bucket elevator or conveyor to the scale infeed, 14-head scale, VFFS bagger, checkweigher, metal detector, inline date/lot coder, labeling system, conveyor, case erector, and case tape sealer. One vendor, one installation, one point of technical accountability. Call 888-814-7999 to discuss your complete line requirements.
Don't let manual weighing limit your throughput or cost you margin with inconsistent overfill. The BPS 14-Head Linear Combination Scale delivers the accuracy and speed your production operation needs — backed by BPSG's 45 years of packaging engineering experience and the Barrington Advantage warranty.
Call 888-814-7999 Request a Consultation All Linear Scale SystemsEach of the 14 heads weighs a charge of product at the same time. The PLC checks the combinations, up to 16,383 for 14 heads, picks the one closest to target weight and discharges it into the tray, bag or pouch below.
It is designed for food manufacturers, produce packers, snack producers and frozen food producers who need weight accuracy and throughput.
Product arrives via an overhead infeed, typically a vibratory conveyor or Z-bucket elevator, and is spread across 14 holding hoppers. Each drops into a scale hopper with a load cell, and discharged heads are refilled right away.
